BeVision S1
يجمع جهاز BeVision S1 بين الفحص المجهري الضوئي وتحليل الصور، مما يوفر توزيعات بديهية ودقيقة لحجم وشكل المسحوق أو المعلقات. عند التكبير الموضوعي الذي يصل إلى 100x، يمكن تحليل حتى الجسيمات الدقيقة التي يصل حجمها إلى 1 ميكرومتر وتسجيلها بكفاءة بواسطة BeVision S1.
الميزات والفوائد
- ● نطاق القياس: 1 إلى 3,000 ميكرومتر
- ● 24 معلمات مختلفة لحجم الجسيمات وشكلها
- ● نماذج اختيارية لتطبيقات مختلفة
- ● قياسات جافة ورطبة على حد سواء
- ● النتائج المتوافقة مع المواصفة ISO 9276-6
- ● حل مناسب للميزانية لتحليل الجسيمات الخاص بك
- ● برنامج قوي يسهل عملك
- ● تقارير قابلة للتخصيص لخيارات التقييم المختلفة
فيديو
لمحة عامة
1) لماذا طريقة تحليل الصور؟
- السهولة
التقاط صورة للجسيمات، وتحديد الجسيمات، ثم قياس حجمها وشكلها. كل خطوة من خطوات تحليل الصور سهلة وواضحة.
- تحليل الشكل
استنادًا إلى عرض مباشر للجسيمات، من الممكن تحليل ليس فقط حجم الجسيمات، ولكن أيضًا شكلها.
- الرؤية واضحة
تحدد طريقة تحليل الصور حجم وشكل كل جسيم على حدة ثم تجمعها لتكوين إحصائية. يمكن توفير تفاصيل حجم الجسيمات أو توزيع شكلها بدقة.
2) لماذا طريقة تحليل الصور الثابتة؟
- الرؤية الواضحة
في أجهزة تحليل الصور الثابتة، يتم تخصيص مجاهر دقيقة وكاميرات عالية الدقة لصور الجسيمات عالية الجودة.
- حساسية الجسيمات صغيرة الحجم
تتميز طريقة تحليل الصور الثابتة بحساسيتها للجسيمات صغيرة الحجم؛ بل إنه من الممكن تقدير حجم الجسيمات صغيرة الحجم.
- حجم العينة الصغير
تتطلب طريقة تحليل الصور الساكنة حجمًا صغيرًا من العينات. تكفي بضع قطرات من المستحلبات أو بضعة ميكروغرامات من المساحيق لإجراء القياس.
3) معلمات حجم الجسيمات وشكلها :
- معلمات الحجم
الأقطار المكافئة: القطر المكافئ للمساحة 、 القطر المكافئ للمساحة 、 القطر المكافئ للمتر؛
أقطار فيريت: الحد الأقصى والأدنى لأقطار فيريت ″الطول″;
أقطار مارتن: أقطار مارتن القصوى والدنيا؛
القطع الناقص الأسطوري: المحاور الكبرى والصغرى;
- معلمات الشكل
فرق الحجم في اتجاهين: نسبة الأبعاد、نسبة الطول إلى العرض、نسبة الطول إلى العرض、نسبة القطع الناقص؛
الاستدارة 、الشبه الدائري والشبه المستطيل الدائرية 、 الدائرية 、 عدم انتظام الشكل 、 الامتداد 、 نسبة التقعر 、 نسبة الصندوق;
تقعر الكفاف التقعر、التحدب、التحدب、التصلب؛
للجسيمات الممدودة: الاستطالة、الاستطالة、الاستقامة;
4) برنامج BeVision: رؤى مرئية لك :
5) التطبيقات النموذجية:
